vwfex06 : User defined Inductor spice model parameters extraction

Requires: VWF, QUEST

This example demonstrates how to extract user defined Inductor SPICE model parameters.

UTMOSTIV will be used to perform spice model parameter extraction. A project in UTMOSTIV has to be created including both the user-defined SPICE model as well as the extraction strategy, and loaded into VWF as a resource.

To open and run this example, select the Help Load example button in the VWF explorer. This will import all examples into your database. Once imported, the examples will be available under the directory called examples.
