PRODUCTION READY IP | STANDARD CELL LIBRARIES

Standard Cell Libraries

Custom standard cell libraries tailored to specific process nodes and application needs. Configurable architectures,
multiple Vt options, and foundry-qualified views accelerate SoC differentiation while reducing risk.

Optimized for Power, Performance, and Area

Designed for both advanced and mature technologies, Silvaco standard cell libraries enable higher frequency, lower leakage, and improved yield. Select from CORE, Power Management Kit (PMK), and ECO libraries with multi-Vt options to tune your design for the target application.

Low-power SoCs for mobile, IoT, and wearables
High-density layouts → increased gross die per wafer
Reduced cost per function and interconnect length
Increased power efficiency across the design
Foundry enablement for TSMC, GlobalFoundries, UMC

Standard Cell Product Selector

Libraries available at the node/foundry combinations below. Click any part number to download the datasheet.
Transistor Vts: RVT (Regular), LVT (Low), HVT (High), UHVT (Ultra-High), ULVT (Ultra-Low), ELVT (Extra-Low).

Part Number	Foundry	Node (nm)	Process	VN	Track Height	Libraries	Transistor Vts	Gate Length (nm)
70350	GF	28	SLP	0.9	8T	CORE, PMK, ECO	RVT, LVT, HVT, ELVT	30, 34, 38
70351	TSMC	40	LP	1.1	7T	CORE	RVT, LVT, HVT	35, 40
70353	GF	55	LPx	0.9	7T	CORE, PMK, ECO	RVT, LVT	60
70354	GF	55	LPx	3.3	10T	CORE	RVT	500
70355	UMC	55	LPeFLASH	0.9	7T	CORE	RVT, LVT, HVT	60
70356	TSMC	65	LP	1.2	12T	CORE	RVT, LVT, HVT	65
70357	TSMC	110	LP	1.2	7T	CORE, PMK, ECO	RVT	110
70359	GF	130	LP	1.2	7T	CORE	RVT, LVT	110
70360	TSMC	180	LP	1.8	7T	CORE, PMK, ECO	RVT	180
70361	GF	180	Bi-CMOS	3.3	7T	CORE	RVT	500

Need a specific node or foundry combination?

Our library team can help identify the right fit — or quote a custom characterization.
