PRODUCTION READY IP | MEMORY COMPILERS

Advanced Memory Compilers

Silicon-proven SP-SRAM, DP-SRAM, ROM, and register file IP across leading foundry nodes. Each compiler generates fully
characterized, DRC/LVS-clean instances with comprehensive Liberty, LEF, and GDSII deliverables.

Configuration-Driven Integration

Optimized for area, power, and performance, Silvaco’s memory IP is purpose-built for rapid SoC integration across automotive, consumer, industrial, and IoT applications. Every instance is foundry-qualified and delivered with characterized views.

Edge computing and IoT low-power/low-leakage designs
Industrial automation, process control, and robotics
Custom SoC designs at mature and advanced nodes
Display drivers and DDICs
Security and cryptographic processors
Audio and voice processing ASICs

Memory Compiler Selector

Part Number	Foundry	Node (nm)	Process	Memory Type	Retention	Size (bits)	Mux	V (Periph)	V (Array)
61250	GF	22	FDX	1 Port Register File	No	128–40k	8	0.8	–
61251	GF	22	FDX+	Single-Port SRAM	No	256–1,024k	4, 8, 16	0.8	–
61252	TSMC	40	uLP	Dual-Port SRAM	Yes	64–288k	4	0.9	1.1
61253	TSMC	40	uLP	Dual-Port SRAM	Yes	64–288k	4	0.9	1.1
61254	TSMC	40	LP	Single-Port SRAM	No	256–576k	4	1.1	–
61255	TSMC	40	ULP eFlash	Via ROM	N/A	1k–1,152k	8–128	1.1	–
61256	TSMC	55	ULP eFlash	Single-Port SRAM	Yes	64–32k	2, 4	1.2	–
61257	TSMC	55	HV	2 Port Register File	No	1k–640k	4	1.2	–
61258	TSMC	55	ULP eFlash	2 Port Register File	No	128–64k	4	1.2	–
61259	TSMC	55	LP eFlash	Dual-Port SRAM	No	256–32k	8	1.2	–
61260	TSMC	55	ULP eFlash	Dual-Port SRAM	No	128–64k	4	1.2	–
61261	TSMC	55	HV	Single-Port SRAM	No	512–320k	8, 16	1.2	–
61262	TSMC	55	ULP eFlash	Via ROM	N/A	512–512k	8–128	1.2	–
61263	GF	55	LPx	Single-Port SRAM	Yes	320k	4, 8, 16	1.2	–
61264	TSMC	90	LP eFlash	Dual-Port SRAM	Yes	256–80k	8	1.2	–
61265	TSMC	110	HV	1 Port Register File	No	128–20k	4, 8	1.5	–
61266	UMC	110	eFlash	Single-Port SRAM	Yes	256–320k	4, 8, 16	1.5	–
61267	TSMC	130	BCD	Single-Port SRAM	No	128–64k	4, 8, 16	1.5	–
61268	TSMC	130	BCD Plus	Single-Port SRAM	No	128–64k	4, 8, 16	1.5	–

Looking for a custom memory configuration?

Our compiler team can tune instances to your exact area, power, and performance targets.
