PRODUCTION READY IP | MIPI PHY AND MORE

Mixel PHY and More

PPA-optimized and silicon-proven IP including MIPI PHY and other SerDes IP for mobile, automotive,
IoT, wearables, edge processing, and other low-power, high-performance applications.

Time to market is your largest risk. Mixel’s Production Ready Offerings (PRO IP) provide proven solutions that are available immediately for you to use in your SoC design targeting mobile and mobile-adjacent markets such as automotive, virtual reality (VR), augmented reality (AR), Internet of Things (IoT), wearables, and sensors. The Mixel PRO IP portfolio includes MIPI PHY such as MIPI D-PHY and MIPI C-PHY, and multi-standard SerDes IP including MIPI C-PHY/D-PHY combo IP and LVDS/D-PHY combo IP.

MIPI C-PHY/D-PHY Combo

Foundry Product Name Features
TSMC C-PHY/D-PHY Combo DSI TX+ in TSMC N5 Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 4.5Gsps/4.5Gbps, full-speed internal loopback testability
TSMC C-PHY/D-PHY Combo CSI RX+ in TSMC N5 Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 4.5Gsps/4.5Gbps, full-speed internal loopback testability
TSMC C-PHY/D-PHY Combo CSI-2 RX+ in TSMC N6 Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 6.0Gsps/4.5Gbps, full-speed internal loopback testability
TSMC C-PHY/D-PHY combo CSI-2 RX in TSMC N7 Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 4.5Gsps/4.5Gbps
TSMC C-PHY/D-PHY Combo CSI-2 TX+ in TSMC 16FFC Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 4.5Gsps/4.5Gbps, full-speed internal loopback testability
TSMC C-PHY/D-PHY Combo DSI RX+  in TSMC 16FFC Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 4.5Gsps/6.5Gbps, full-speed internal loopback testability
TSMC C-PHY/D-PHY Combo Universal  in TSMC 16FFC Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 8.0Gsps/6.5Gbps, full-speed internal loopback testability
TSMC C-PHY/D-PHY Combo DSI RX in TSMC 22ULP Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 2.5Gsps/2.5Gbps
TSMC C-PHY/D-PHY Combo CSI-2 TX  in TSMC 22ULL Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 2.5Gsps/2.5Gbps
TSMC C-PHY/D-PHY Combo CSI-2 TX in TSMC 28HPC+ Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 4.5Gsps/4.5Gbps
ST C-PHY/D-PHY Combo CSI-2 TX+ in ST 28FDSOI Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 3.5Gsps/2.5Gbps, full-speed internal loopback testability
ST C-PHY/D-PHY Combo CSI-2 TX+ in ST 40LP Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 3.5Gsps/2.5Gbps, full-speed internal loopback testability
ST C-PHY/D-PHY Combo CSI-2 TX+ in ST 40LP Supports MIPI C-PHY and MIPI D-PHY, 2T/2L, 3.5Gsps/2.5Gbps, full-speed internal loopback testability
TSMC C-PHY/D-PHY Combo CSI-2 TX in TSMC 40ULP Supports MIPI C-PHY and MIPI D-PHY, 2T/2L, 1.5Gsps/1.5Gbps
TSMC C-PHY/D-PHY Combo CSI-2 TX+  in TSMC 40ULP Supports MIPI C-PHY and MIPI D-PHY, 1T/1L, 2.5Gsps/2.5Gbps, full-speed internal loopback testability
TSMC C-PHY/D-PHY Combo CSI-2 TX+  in TSMC 40ULP Supports MIPI C-PHY and MIPI D-PHY, 2T/2L, 2.5Gsps/2.5Gbps, full-speed internal loopback testability
TSMC C-PHY/D-PHY Combo CSI-2 TX+ in TSMC 65LP Supports MIPI C-PHY and MIPI D-PHY, 1L/1T, 1.5Gsps/1.5Gbps, full-speed internal loopback testability

MIPI D-PHY

Foundry Product Name Features
TSMC D-PHY DSI TX  in TSMC N7 Supports MIPI D-PHY, 4L, 4.5Gbps
TSMC D-PHY CSI-2 RX in TSMC 16FFC Supports MIPI D-PHY, 4L, 1.25Gbps
TSMC D-PHY Universal  in TSMC 22ULP Supports MIPI D-PHY, 4L, 2.5Gbps, full-speed internal loopback testability
TSMC D-PHY Universal in TSMC 22ULP Supports MIPI D-PHY, 2L, 2.5Gbps, full-speed internal loopback testability
TSMC D-PHY Universal in TSMC 22ULP Supports MIPI D-PHY, 1L, 2.5Gbps, full-speed internal loopback testability
GlobalFoundries D-PHY CSI-2 TX in GF 22FDX Supports MIPI D-PHY, 4L, 2.5Gbps
GlobalFoundries D-PHY CSI-2 RX in GF 22FDX Supports MIPI D-PHY, 4L, 2.5Gbps
GlobalFoundries D-PHY CSI-2 RX  in GF 22FDX Supports MIPI D-PHY, 2L, 2.5Gbps
GlobalFoundries D-PHY CSI-2 TX in GF 22FDX Supports MIPI D-PHY, 2L, 2.5Gbps
TSMC D-PHY CSI-2 TX in TSMC 22ULL Supports MIPI D-PHY, 1L, 1.5Gbps, full-speed internal loopback testability
TSMC D-PHY CSI-2 TX+ in TSMC 22ULL Supports MIPI D-PHY, 4L, 2.5Gbps, full-speed internal loopback testability
UMC D-PHY DSI RX  in UMC 22ULP/22ULL Supports MIPI D-PHY, 4L, 2.5Gbps
GlobalFoundries D-PHY DSI RX  in GF 22FDX Supports MIPI D-PHY, 4L, 2.5Gbps
GlobalFoundries D-PHY DSI TX+ in GF 22FDX+ Supports MIPI D-PHY, 2L, 2.5Gbps, full-speed internal loopback testability
GlobalFoundries D-PHY CSI-2 RX in GF 22FDX+ Supports MIPI D-PHY, 2L, 2.5Gbps
GlobalFoundries D-PHY DSI-2 RX in GF 22FDX+ Supports MIPI D-PHY, 2L, 2.5Gbps
TSMC D-PHY Universal in TSMC 22ULL Supports MIPI D-PHY, 4L, 2.5Gbps, full-speed internal loopback testability
TSMC D-PHY CSI-2 TX+ in TSMC 28HPC+ Supports MIPI D-PHY, 4L, 2.5Gbps, full-speed internal loopback testability
Samsung D-PHY DSI TX+ in Samsung 28FDSOI Supports MIPI D-PHY, 4L, 1.5Gbps, full-speed internal loopback testability
Samsung D-PHY CSI-2 RX in Samsung 28FDSOI Supports MIPI D-PHY, 2L, 1.5Gbps
TSMC D-PHY Universal in TSMC 28HPC+ Supports MIPI D-PHY, 4L, 2.5Gbps, full-speed internal loopback testability
TSMC D-PHY CSI-2 RX+ in TSMC 28HPC+ Supports MIPI D-PHY, 2L, 1.5Gbps, full-speed internal loopback testability
TSMC D-PHY DSI TX in TSMC 28HPC+ Supports MIPI D-PHY, 4L, 2.5Gbps
TSMC D-PHY CSI-2 RX in TSMC 28HPC+ Supports MIPI D-PHY, 4L, 2.5Gbps
TSMC D-PHY CSI-2 TX in TSMC 28HPC+ Supports MIPI D-PHY, 2L, 2.5Gbps
TSMC D-PHY Universal in TSMC 28HPC+ Supports MIPI D-PHY, 4L, 2.5Gbps, full-speed internal loopback testability
TSMC D-PHY Universal in TSMC 40LP Supports MIPI D-PHY, 1L, 1.5Gbps, full-speed internal loopback testability
TSMC D-PHY CSI-2 TX+ in TSMC 40ULP Supports MIPI D-PHY, 1L, 1.5Gbps, full-speed internal loopback testability
TSMC D-PHY CSI-2 TX+ in TSMC 40ULP Supports MIPI D-PHY, 4L, 1.5Gbps, full-speed internal loopback testability
TSMC D-PHY CSI-2 TX in TSMC 40LP Supports MIPI D-PHY, 4L, 2.5Gbps
TSMC D-PHY DSI TX in TSMC 55ULP Supports MIPI D-PHY, 2L, 1.0Gbps
TSMC D-PHY Universal in TSMC 65GP Supports MIPI D-PHY, 4L, 2.5Gbps, full-speed internal loopback testability
Tower D-PHY CSI-2 TX in Tower 65ISC Supports MIPI D-PHY, 4L, 1.2Gbps
TSMC D-PHY CSI-2 TX in TSMC 65LP Supports MIPI D-PHY, 2L, 2.5Gbs
Tower D-PHY CSI-2 TX in Tower 65ISC Supports MIPI D-PHY, 2L, 1.2Gbps
TSMC D-PHY CSI-2 TX in TSMC 90LP Supports MIPI D-PHY, 4L, 2.5Gbps
TSMC D-PHY CSI-2 TX+ in TSMC 90LP Supports MIPI D-PHY, 4L, 2.5Gbps, full-speed internal loopback testability

MIPI C-PHY

Foundry Product Name Features
TSMC C-PHY DSI TX in TSMC 22ULL Supports MIPI C-PHY, 3T, 2.5Gsps
TSMC C-PHY DSI RX in TSMC 22ULL Supports MIPI C-PHY, 3T, 2.5Gsps
TSMC C-PHY CSI-2 TX+ in TSMC 40ULP Supports MIPI C-PHY, 1T, 2.5Gsps, full-speed internal loopback testability

LVDS/MIPI D-PHY Combo

Foundry Product Name Features
GlobalFoundries LVDS/D-PHY DSI TX+ combo in GF 22FDX+ Supports MIPI D-PHY and LVDS, 4CH/4L, 1039.5Mbps/2.5Gbps, full-speed internal loopback testability
TSMC LVDS/D-PHY CSI-2 RX Combo in TSMC 28HPC+ Supports MIPI D-PHY and LVDS, 4CH/4L, 600Mbps/1.5Gbps
Tower LVDS/D-PHY CSI-2 TX Combo in Tower 65BSB Supports MIPI D-PHY and LVDS, 3CH/2L, 600Mbps/1.2Gbps

MIPI LVDS

Foundry Product Name Features
UMC LVDS TX+ in UMC 40ULP Supports LVDS, 4CH, 770Mbps, full speed loopback description
TSMC LVDS TX in TSMC 40LP Supports LVDS, 4CH, 1000Mbps
TSMC LVDS RX in TSMC 40LP Supports LVDS, 4CH, 1000Mbps

Looking for a different foundry, process, or IP configuration?

Our team of mixed-signal design experts are here to help. Reach out below for a technical consultation.
