Mixel is a provider of mixed-signal IPs and offers a wide portfolio of high-performance mixed-signal connectivity IP solutions. Mixel’s mixed-signal portfolio includes PHYs and SerDes, such as MIPI D-PHYTM, MIPI M-PHY®, MIPI C-PHYTM, Automotive SerDes Alliance (ASA) Motion Link SerDes, LVDS, and many dual mode PHY supporting multiple standards.
Mixel’s “Production Ready Offerings” (PRO IP) provide proven solutions that are available immediately for you to use in your SoC design targeting mobile and mobile-adjacent markets such as automotive, virtual reality (VR), augmented reality (AR), Internet of Things (IoT), wearables, and sensors. The Mixel PRO IP portfolio includes MIPI PHY such as MIPI D-PHY and MIPI C-PHY, and multi-standard SerDes IP including MIPI C-PHY/D-PHY combo IP and LVDS/D-PHY combo IP.
| Interface IP | Foundry | Product Name | Features |
|---|---|---|---|
| MIPI C-PHY/D-PHY Combo | TSMC | C-PHY/D-PHY Combo DSI TX+ in TSMC N5 | Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 4.5Gsps/4.5Gbps, full-speed internal loopback testability |
| TSMC | C-PHY/D-PHY Combo CSI RX+ in TSMC N5 | Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 4.5Gsps/4.5Gbps, full-speed internal loopback testability | |
| TSMC | C-PHY/D-PHY Combo CSI-2 RX+ in TSMC N6 | Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 6.0Gsps/4.5Gbps, full-speed internal loopback testability | |
| TSMC | C-PHY/D-PHY combo CSI-2 RX in TSMC N7 | Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 4.5Gsps/4.5Gbps | |
| TSMC | C-PHY/D-PHY Combo CSI-2 TX+ in TSMC 16FFC | Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 4.5Gsps/4.5Gbps, full-speed internal loopback testability | |
| TSMC | C-PHY/D-PHY Combo DSI RX+ in TSMC 16FFC | Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 4.5Gsps/6.5Gbps, full-speed internal loopback testability | |
| TSMC | C-PHY/D-PHY Combo Universal in TSMC 16FFC | Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 8.0Gsps/6.5Gbps, full-speed internal loopback testability | |
| TSMC | C-PHY/D-PHY Combo DSI RX in TSMC 22ULP | Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 2.5Gsps/2.5Gbps | |
| TSMC | C-PHY/D-PHY Combo CSI-2 TX in TSMC 22ULL | Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 2.5Gsps/2.5Gbps | |
| TSMC | C-PHY/D-PHY Combo CSI-2 TX in TSMC 28HPC+ | Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 4.5Gsps/4.5Gbps | |
| ST | C-PHY/D-PHY Combo CSI-2 TX+ in ST 28FDSOI | Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 3.5Gsps/2.5Gbps, full-speed internal loopback testability | |
| ST | C-PHY/D-PHY Combo CSI-2 TX+ in ST 40LP | Supports MIPI C-PHY and MIPI D-PHY, 3T/4L, 3.5Gsps/2.5Gbps, full-speed internal loopback testability | |
| ST | C-PHY/D-PHY Combo CSI-2 TX+ in ST 40LP | Supports MIPI C-PHY and MIPI D-PHY, 2T/2L, 3.5Gsps/2.5Gbps, full-speed internal loopback testability | |
| TSMC | C-PHY/D-PHY Combo CSI-2 TX in TSMC 40ULP | Supports MIPI C-PHY and MIPI D-PHY, 2T/2L, 1.5Gsps/1.5Gbps | |
| TSMC | C-PHY/D-PHY Combo CSI-2 TX+ in TSMC 40ULP | Supports MIPI C-PHY and MIPI D-PHY, 1T/1L, 2.5Gsps/2.5Gbps, full-speed internal loopback testability | |
| TSMC | C-PHY/D-PHY Combo CSI-2 TX+ in TSMC 40ULP | Supports MIPI C-PHY and MIPI D-PHY, 2T/2L, 2.5Gsps/2.5Gbps, full-speed internal loopback testability | |
| TSMC | C-PHY/D-PHY Combo CSI-2 TX+ in TSMC 65LP | Supports MIPI C-PHY and MIPI D-PHY, 1L/1T, 1.5Gsps/1.5Gbps, full-speed internal loopback testability | |
| MIPI D-PHY | TSMC | D-PHY DSI TX in TSMC N7 | Supports MIPI D-PHY, 4L, 4.5Gbps |
| TSMC | D-PHY CSI-2 RX in TSMC 16FFC | Supports MIPI D-PHY, 4L, 1.5Gbps | |
| TSMC | D-PHY Universal in TSMC 22ULP | Supports MIPI D-PHY, 4L, 2.5Gbps, full-speed internal loopback testability | |
| TSMC | D-PHY Universal in TSMC 22ULP | Supports MIPI D-PHY, 2L, 2.5Gbps, full-speed internal loopback testability | |
| TSMC | D-PHY Universal in TSMC 22ULP | Supports MIPI D-PHY, 1L, 2.5Gbps, full-speed internal loopback testability | |
| GlobalFoundries | D-PHY CSI-2 TX in GF 22FDX | Supports MIPI D-PHY, 4L, 2.5Gbps | |
| GlobalFoundries | D-PHY CSI-2 RX in GF 22FDX | Supports MIPI D-PHY, 4L, 2.5Gbps | |
| GlobalFoundries | D-PHY CSI-2 RX in GF 22FDX | Supports MIPI D-PHY, 2L, 2.5Gbps | |
| GlobalFoundries | D-PHY CSI-2 TX in GF 22FDX | Supports MIPI D-PHY, 2L, 2.5Gbps | |
| TSMC | D-PHY CSI-2 TX in TSMC 22ULL | Supports MIPI D-PHY, 1L, 1.5Gbps, full-speed internal loopback testability | |
| TSMC | D-PHY CSI-2 TX+ in TSMC 22ULL | Supports MIPI D-PHY, 4L, 2.5Gbps, full-speed internal loopback testability | |
| UMC | D-PHY DSI RX in UMC 22ULP/22ULL | Supports MIPI D-PHY, 4L, 2.5Gbps | |
| GlobalFoundries | D-PHY DSI RX in GF 22FDX | Supports MIPI D-PHY, 4L, 2.5Gbps | |
| GlobalFoundries | D-PHY DSI TX+ in GF 22FDX+ | Supports MIPI D-PHY, 2L, 2.5Gbps, full-speed internal loopback testability | |
| GlobalFoundries | D-PHY CSI-2 RX in GF 22FDX+ | Supports MIPI D-PHY, 2L, 2.5Gbps | |
| GlobalFoundries | D-PHY DSI-2 RX in GF 22FDX+ | Supports MIPI D-PHY, 2L, 2.5Gbps | |
| TSMC | D-PHY Universal in TSMC 22ULL | Supports MIPI D-PHY, 4L, 2.5Gbps, full-speed internal loopback testability | |
| TSMC | D-PHY CSI-2 TX+ in TSMC 28HPC+ | Supports MIPI D-PHY, 4L, 2.5Gbps, full-speed internal loopback testability | |
| Samsung | D-PHY DSI TX+ in Samsung 28FDSOI | Supports MIPI D-PHY, 4L, 1.5Gbps, full-speed internal loopback testability | |
| Samsung | D-PHY CSI-2 RX in Samsung 28FDSOI | Supports MIPI D-PHY, 2L, 2.5Gbps | |
| TSMC | D-PHY Universal in TSMC 28HPC+ | Supports MIPI D-PHY, 4L, 2.5Gbps, full-speed internal loopback testability | |
| TSMC | D-PHY CSI-2 RX+ in TSMC 28HPC+ | Supports MIPI D-PHY, 2L, 1.5Gbps, full-speed internal loopback testability | |
| TSMC | D-PHY DSI TX in TSMC 28HPC+ | Supports MIPI D-PHY, 4L, 2.5Gbps | |
| TSMC | D-PHY CSI-2 RX in TSMC 28HPC+ | Supports MIPI D-PHY, 4L, 2.5Gbps | |
| TSMC | D-PHY CSI-2 RX in TSMC 28HPC+ | Supports MIPI D-PHY, 4L, 2.5Gbps | |
| TSMC | D-PHY CSI-2 TX in TSMC 28HPC+ | Supports MIPI D-PHY, 2L, 2.5Gbps | |
| TSMC | D-PHY Universal in TSMC 28HPC+ | Supports MIPI D-PHY, 4L, 2.5Gbps, full-speed internal loopback testability | |
| TSMC | D-PHY Universal in TSMC 40LP | Supports MIPI D-PHY, 1L, 1.5Gbps, full-speed internal loopback testability | |
| TSMC | D-PHY CSI-2 TX+ in TSMC 40ULP | Supports MIPI D-PHY, 4L, 1.5Gbps, full-speed internal loopback testability | |
| TSMC | D-PHY CSI-2 TX+ in TSMC 40ULP | Supports MIPI D-PHY, 4L, 1.5Gbps, full-speed internal loopback testability | |
| TSMC | D-PHY CSI-2 TX in TSMC 40LP | Supports MIPI D-PHY, 4L, 2.5Gbps | |
| TSMC | D-PHY DSI TX in TSMC 55ULP | Supports MIPI D-PHY, 4L, 1.0Gbps | |
| TSMC | D-PHY Universal in TSMC 65GP | Supports MIPI D-PHY, 4L, 2.5Gbps, full-speed internal loopback testability | |
| Tower | D-PHY CSI-2 TX in Tower 65ISC | Supports MIPI D-PHY, 4L, 1.2Gbps | |
| TSMC | D-PHY CSI-2 TX in TSMC 65LP | Supports MIPI D-PHY, 2L, 2.5Gbs | |
| Tower | D-PHY CSI-2 TX in Tower 65ISC | Supports MIPI D-PHY, 2L, 1.2Gbps | |
| TSMC | D-PHY CSI-2 TX in TSMC 90LP | Supports MIPI D-PHY, 4L, 2.5Gbps | |
| TSMC | D-PHY CSI-2 TX+ in TSMC 90LP | Supports MIPI D-PHY, 4L, 2.5Gbps, full-speed internal loopback testability | |
| MIPI C-PHY | TSMC | C-PHY DSI TX in TSMC 22ULL | Supports MIPI C-PHY, 3T, 2.5Gsps |
| TSMC | C-PHY DSI RX in TSMC 22ULL | Supports MIPI C-PHY, 3T, 2.5Gsps | |
| TSMC | C-PHY CSI-2 TX+ in TSMC 40ULP | Supports MIPI C-PHY, 1T, 2.5Gsps, full-speed internal loopback testability | |
| MIPI LVDS/D-PHY Combo | GlobalFoundries | LVDS/D-PHY DSI TX+ combo in GF 22FDX+ | Supports MIPI D-PHY and LVDS, 4CH/4L, 1039.5Mbps/2.5Gbps, full-speed internal loopback testability |
| TSMC | LVDS/D-PHY CSI-2 RX Combo in TSMC 28HPC+ | Supports MIPI D-PHY and LVDS, 4CH/4L, 600Mbps/1.5Gbps | |
| Tower | LVDS/D-PHY CSI-2 TX Combo in Tower 65BSB | Supports MIPI D-PHY and LVDS, 4CH/4L, 600Mbps/1.2Gbps | |
| MIPI LVDS | UMC | LVDS TX+ in UMC 40ULP | Supports LVDS, 4CH, 700Mbps, full speed loopback description. |
| TSMC | LVDS TX in TSMC 40LP | Supports LVDS, 4CH, 1000Mbps | |
| TSMC | LVDS RX in TSMC 40LP | Supports LVDS, 4CH, 1000Mbps |
